Features for the Ariens Zoom 34

The Ariens Zoom 34 Zero Turn Mower is the perfect introductory zero turn for homeowners that have tighter spaces to mow around their yards, and don't need a wide deck. A 34” Xlerator 2-blade mowing deck delivers a better cut with less scalping. Fully adjustable control arms ensure that you will be comfortable while you mow. This zero turn is compact, durable, and comfortable for those looking to switch to zero turn functionality from a lawn tractor.

• Powerful Kohler Engine:19HP/660cc Kohler 6600 Series V-Twin 4-Cycle Engine.
• Hydro-Gear EZT Transmissions:No shifting, speed adjusts based on the operators control, plus these transmissions come equipped with cooling fans and a large hydraulic reservoir
• Xlerator Mowing Deck:12 gauge stamped steel deck with 2 blades (17,000 feet/minute blade tip speed) and maintenance free spindles.
• Durable Construction:1.5” x 1.5” fully welded steel frame and a 12 gauge stamped steel deck means durability!
• Adjustable Control Arms:Chose from 3 positions for the control arms to achieve maximum comfort
• Mid-Back Padded Seat:For operator comfort

Technical Specs for the Ariens Zoom 34

Engine
Engine Manufacturer : Kohler
Cylinders : 2
Fuel Capacity : 2 gal
Oil Filter : Yes
Engine : Kohler 6000 Series V-Twin 4-Cycle Engine
Displacement(cc) : 660cc
Power : 19HP

Drive System
Transmission Type : Hydrostatic
Transmission Manufacturer : Hydro-Gear EZT
Speed Forward (min, max) : 0-6 mph
Speed Reverse (min, max) : 0-3 mph
Tire Size (front, rear) : 11 x 4 inches, 18 x 8.5 inches

Cutting Deck
Cutting Width : 34 inches
Deck Thickness : 12 Gauge
Cutting Deck Type : Stamped
Cutting Height (min-max) : 1.5 - 4.5 inches
Cutting Height Steps : 7
Blades : 2
Blade Engagement : Warner Electric
Wash Out Port : Yes
Deck Lift System : Manual, Foot Assisted

Features
Seat Back Height : Mid-Back

Warranty
Residential Warranty : 3 years

Dimensions
Length (in.) : 64 inches
Width (in.) : 35 inches (chute up), 42 inches (chute down)

Cutting Deck
Anti-scalp Wheels : No
