Quincy reciprocating air compressors are designed to be a compressor for life. They are built for efficiency and lower operating costs, producing more compressed air at a lower horsepower. They run at a slower RPM, run cooler and cost less to operate. Heavy-duty compressors are engineered for industrial applications and boast an industry-leading 50,000-hour pump life rating. One-year limited warranty without warranty kit purchase. Purchase an extended warranty kit (Item# 42637) at the same time (on the same receipt) as your Quincy 80-gallon air compressor and it will double the package warranty to 2 years and triple the pump warranty to 3 years (on-site parts and labor included). U.S.A.

• (1) Compressor

• Features + Benefits

  • Industrial-duty US-made motor
  • Capacitor start motor with built-in thermal overload
  • Less than 5 PPM oil carry-over (blow-by) rating
  • 145–175 working PSI
  • Pump RPM: 942
  • 2-cylinder pump design
  • Heavy-duty, easy-to-reach, manual ball valve
  • 2-stage belt drive pump with solid cast iron cylinder
  • Finned tube intercooler for maximum cooling and increased valve life

  • Aluminum head for heat dissipation
  • Extra-capacity oil reservoir for low oil temperatures
  • Cast iron fly wheel for energy efficiency and durability
  • 100% duty cycle
  • Splash lubrication
  • UL & CSA approval on all electrical components
  • ASME-coded pressure relief valves and tanks
  • Additional charge for liftgate shipping option
  • Ships in heavy-duty protective crate with oil in the pump
  Key Specs

  Item#	37846
  Brand	Quincy Compressor
  Manufacturer's Warranty	12 months parts / 12 months labor
  Ship Weight	625.0 lbs
  Volts	230
  Max. PSI	175
  Pump Life (hrs.)	50,000+
  Air Tank Size (gal.)	80
  CFM at 90 PSI	17.7
  CFM at Max. PSI	17.2
  Air Outlet Size (in.)	3/4
  Duty Cycle	100%

  Working Pressure (PSI)	145–175
  Stage	2
  Motor Phase(s)	Single
  Oil Required	Yes
  Lubrication System	Splash
  HP	5
  Amps	28
  Motor RPM	1,750
  Drain System	Manual
  Pump Material	Cast iron w/aluminum head
  Dimensions L x W x H (in.)	37 x 24 x 74
