Quincy QT-10 Reciprocating Air Compressor – 10 HP, 208/230/460 Volt, 3 Phase, 120-Inch Horizontal

Home
Air Tools & Compressors
Quincy QT-10 Splash Lubricated Reciprocating Air Compressor - 10 HP, 208/230/460 Volt, 3 Phase, 120-Gallon Horizontal

Home
Electric Air Compressors
Quincy QT-10 Splash Lubricated Reciprocating Air Compressor - 10 HP, 208/230/460 Volt, 3 Phase, 120-Gallon Horizontal

Quincy QT-10 Splash Lubricated Reciprocating Air Compressor - 10 HP, 208/230/460 Volt, 3 Phase, 120-Gallon Horizontal

Price:

$1,550.00

SKU:

QCY-QT10-120H-3PH

Brand:

Quincy

Condition:

New

Weight:

0.00 LBS

Availability:

In Stock

Shipping:

Calculated at checkout

Product Description

Quincy QT reciprocating air compressors are designed to be a compressor for life. They are built for efficiency and lower operating costs, producing more compressed air at a lower horsepower. They run at a slower RPM, run cooler and cost less to operate. Heavy-duty compressors are engineered for industrial applications and boast a best-in-the-industry 50,000-hour pump life rating. MAX configuration features automatic tank drain, low oil shutdown and heavy-duty aftercooler included. U.S.A.

What's Included

(1) Compressor

Features + Benefits

Heavy-duty industrial motor
Industrial-duty general-purpose mounted and wired magnetic starter
Less than 5 PPM oil carry-over (blow-by) rating
145–175 working PSI
Motor RPM: 1,750
Pump RPM: 1,025
2-cylinder pump design
2-stage belt drive pump with solid cast iron cylinder
Finned tube intercooler for maximum cooling and increased valve life
Aluminum head for heat dissipation

Extra-capacity oil reservoir for low oil temperatures
Cast iron fly wheel for energy efficiency and durability
100% duty cycle
Splash lubrication
Low oil shutdown
Heavy-duty aftercooler
UL & CSA approval on all electrical components
ASME-coded pressure relief valves and tanks
Additional charge for liftgate shipping option

Key Specs

Item#	3566578
Brand	Quincy Compressor
Manufacturer's Warranty	12 months parts / 12 months labor
Ship Weight	720.0 lbs
Volts	230
Max. PSI	175
Pump Life (hrs.)	50,000+
Air Tank Size (gal.)	80
CFM at Max. PSI	22.6
Air Outlet Size (in.)	3/4
Duty Cycle	100%

Working Pressure (PSI)	145–175
Stage	2
Motor Phase(s)	Single
HP	7.5
Amps	40
Motor RPM	1,750
Drain System	Automatic
Pump Material	Cast iron
Noise Level (dB)	78
Dimensions L x W x H (in.)	37 x 24 x 74
