Power Output | 20kW |
Type | Synchronous |
Rotor Insulation Class | H |
Stator Insulation Class | H |
Telephone Interference Factor (TIF) | Less than 50 |
Alternator Output Leads 1-Phase | 3 wire |
Alternator Output Leads 3-Phase | 6 wire |
Bearings | Single Sealed Cartridge |
Coupling | Direct, Flexible Disc |
Excitation System | Direct |
Voltage Regulation | |
---|---|
Type | Electronic |
Sensing | Single Phase |
Regulation | +/- 1% |
Features | Adjustable Voltage and Gain |
Governor Specifications | |
Type | Electronic Isochronous |
Steady State Regulation | +/- 0.25% |
Electrical System | |
Battery Charge Alternator | 50 Amp |
Static Battery Charger | 2 Amp |
Recommended Battery | Group 27F, 700 CCA |
System Voltage | 12 Volts |
Engine Specifications | |
Model | In-line |
Cylinders | 4 |
Displacement (Liters) | 2.28 |
Bore (in/mm) | 3.46/88 |
Stroke (in/mm) | 3.70/94 |
Compression Ratio | 21.3:1 |
Intake Air System | Naturally Aspirated |
Cylinder Head Type | Cast Iron OHV |
Piston Type | Emergency Stationary |
EPA Emissions Compliance | Emergency Stationary |
Engine Lubrication System | |
Oil Pump Type | Gear |
Oil Filter Type | Full flow spin-on cartridge |
Crankcase Capacity (qt/l) | 6.87/6.5 |
Engine Cooling System | |
Type | Pressurized radiator |
Water Pump | Pre-lubed, self-seating |
Fan Speed (rpm) | 1800 |
Fan Diameter (in/mm) | 18.11/460 |
Fan Mode | Pusher |
Fuel System | |
Fuel Type | Ultra Low Sulfur Diesel Fuel |
Fuel Pump Type | Mechanical Engine Driven Gear |
Injector Type | Mechanical |
Fuel Supply Line (mm/in) | 7.94/0.31 (ID) |
Fuel Return Line (mm/in) | 7.94/0.31(ID) |
Fuel Specification | ASTM |
Fuel Filtering (microns) | 5 |
Tank Specifications | |
Total Size (gallons/liters) | 34/128.7 |
Usable Size (gallons/liters) | 32/121.1 |
Run Time @ 1/2 Load (hrs) | 31 |
